WISH PER BINARIO TRIFASE

Lighting element designed as part of the 3f rail system. It helps to illuminate the selected zone in a targeted way and at the same time allows you to adjust the intensity of the light according to the current situation.

Compatibility and use in the system

This is a system component for the 3f rail system, which you will use when assembling your own light line. As part of the rail system, it works in conjunction with the other elements of the system and allows you to more precisely fine-tune the direction and use of light in the space.

Component Key Properties for 3f Bar System WISH 20 DIMM for 3-circuit tracks THREE CIRCLE. LIST

• Luminous flux of 1600 lm to illuminate the desired zone.
• Chromaticity temperature 3000 K for warm white light.
• The dimmable design allows you to adjust the intensity of the light to the situation.
• A light source is part of the package, so assembly is easier.
• A power transformer is included in the package, which makes installation more straightforward.
• Light angle 36° for targeted light scattering.
• 90° tilt to direct the light.
• 350° rotation for precise light direction.

Technical context and installation

As it is a component for the 3f rail system, it is mounted as part of the finished rail assembly. The package includes a light source and a power transformer, so you can get started with the installation faster and focus on the resulting direction of light in the space.
